Power
7.0 Watts

HD/SD-SDI Input
Number of Inputs: 1
Input equalization to 100 meters of Belden 1694
Auto sensing: Yes

HD/SDI-SDI Reclock Outputs
Four

HD/SD-SDI Processed Outputs
Four

Formats supported
1080i @ 60Hz, 59.94Hz, 50Hz
1080p @ 30Hz, 29.97Hz, 24Hz, 23.98Hz
1080psf @ 24Hz, 23.98Hz
720p @ 60Hz, 59.94Hz, 50Hz, 30Hz, 29.97Hz, 24Hz, 23.98Hz
625i @ 50Hz
525i @ 59.94Hz

Embedded Audio
Passes through card: Yes
Compensation for asynchronous inputs (drops and dupes): No

Frame Sync Delay
Minimum: 3 lines
Maximum: 3 lines + 1 Frame
Delay with FS disabled: > 200 samples

Additional Frames of Delay
HD: 6
SD: 13

RGB Color Correction:
RGB Black Adjust (one per primary): -100% to 100% in 0.1% steps
RGB White Adjust (one per primary): 0% to 200% in 0.1% steps
RGB Gamma Control (one per primary): 0.125 to 8.0 in 0.001 steps

YCbCr Processing Amp:
White Adjust (Gain): 0 to 200% in 0.1% steps
Black Adjust (Lift): -100% to 100% in 0.1% steps
C Gain (Saturation): 0% to 200% in 0.1% steps
Color Phase: -360° to + 360° in 0.1 degree steps

YCbCr Clipper:
Y Black hard clip (values limited at or above): -6.8% to 50% in 0.1% steps
Y White hard clip (values limited at or below): 50% to 109.1% in 0.1% steps
Y White soft clip (values rolled off at): 50% to 109.1% in 0.1% steps
CbCr Saturation clip (values limited at or below): 50% to 160% in 0.1% steps
