(This product is discontinued. Please see 9904-UDX-4K plus Indigo 2110-DC-01 for its replacement.)
The Cobalt® 9904-UDX-4K-IP12G/6G/3G/HD/SD UHD Up/Down/Cross Converter/Frame Sync with Dual 10GigE IP Ports is Cobalt’s next generation of advanced scaler/frame synchronizers for the openGear® platform.
The 9904-UDX-4K-IP upconverts 12G/6G/3G/HD/SD to either UHD1 3840x2160 Square DIvision Multiplex (SDM) or Two-Sample Interleave (2SI) quad 3G-SDI based formats, or can output ST 2082 12G-SDI for single-wire 4K transport. With both 12G-SDI and quad 3G-SDI inputs, the 9904-UDX-4K can downconvert 12G and quad UHD. The 9904-UDX-4K provides an HDMI 2.0 output for economical 4K video monitoring. The 9904-UDX-4K-IP offers numerous options, including SDR-to-HDR conversion and color correction.
The 9904-UDX-4K-IP can provide dual 10GigE ports providing support for the emerging uncompressed video/audio/data over IP standards.
The high-density openGear® design allows for up to five 9904-UDX-4K-IP cards to be installed in one 2RU openGear® frame. Card control/monitoring is available via DashBoard user interface or Cobalt’s RESTful-based Reflex protocol.
