Electrical
Power: 10 watts

Analog Video Input
HD Standard: YPbPr or RGB SMPTE
SD Standard: Composite, Y/C or Component
(YPbPr BetaCam™, MII™ or
SMPTE/N10)
Impedance: 75 Ω

Processing
A/D Converson: HD: 4:4:4 SD: 8:8:8
Quantization: 12-bit A to D and 10-bit video
data path
SD Comb Filter: 5-line adaptive
Freq. Response: HD: Y - 0-25 MHz +/- 0.3 dB
HD: Pb, Pr 0-13.5 MHz
+/-0.3 dB
SD: 5.2 MHz +/- 0.25 dB

HD/SD-SDI Output
Number of Outputs: 4 processed
Standard: SMPTE 292 and 259M
Signal Level: 800 mV nominal
Return Loss: >15 dB at 5 MHz - 270 MHz
>12 dB at 270 MHz - 1.485 GHz
Jitter: HD: < 0.15 UI
SD: < 0.10 UI
